Packaging Machine Troubleshooting

To effectively deal with packaging machine failures and minimize those expensive downtime, you must immediately implement a systematic four-point diagnostic process.First, check the PLC error code on the HMI screen to determine whether an electronic fault or an emergency stop is triggered. Secondly, check the sealing knife and heating element to see if there is temperature fluctuation or carbon deposition, which is the main cause of lax sealing and bag leakage. Third, by verifying the alignment of the film roll, adjusting the tension roller and ensuring that the forming cylinder is free of debris, the problem of film running stuck or offset is solved. Finally, confirm that the air pressure has reached the required PSI value, and clean all photoelectric sensors to eliminate timing errors or inaccurate cut-off positions.

By keeping an eye on the mechanical and electrical interfaces of these cores—seals, membrane feeds, sensors and pneumatic supplies—you can instantly solve more than 90% of production shutdowns and restore the production line to the best OEE (global equipment efficiency).

Step1: Analyzing PLC Error Codes

The human machine interface (HMI) is the “brain” of your packaging line diagnostics. When the machine is stopped, do not attempt a physical reset before reading the PLC log.

Common Misclassification

You need to figure out the difference between a “soft fault” (which can be eliminated by resetting) and a “hard fault” (which requires mechanical intervention).

Emergency Stop Diagnosis

Many times, the machine stops not because of mechanical damage, but because the safety circuit is interrupted. According to my experience, this kind of situation is often caused by the safety door not closed tightly or a loose cable.

Professional Advice

Record frequent error codes in the maintenance log. This can help you find the signs before a major part fails and achieve preventive maintenance instead of waiting for something to happen.

Step2: Heat, Pressure And Surface Maintenance

Leaking bags are the most common complaint in packaging production.

Temperature Stability

Temperature fluctuations often result from aging thermocouples or malfunctioning solid state relays (SSRs). I am used to using an external infrared thermometer to review the HMI readings to see if the true temperature on the surface of the sealing knife is correct.

Clean Up Carbon Deposits

Over time, the film residue will form carbon deposits on the sealing knife, resulting in uneven heating surface. At the handover of each shift, the sealing knives must be cleaned with non-abrasive industrial cleaning agents. Don’t be lazy, this can effectively prevent insufficient sealing strength.

Mechanical Pressure

Ensure uniform sealing pressure. If one side of the bag is not sealed firmly, it may be that the mechanical level of the sealing knife needs to be recalibrated.

GDS210B-08

Single-layer PE, PE composite film, paper film and other composite films

GET QUOTE

Vertical Packing

Vertical sealing servo, heat sealing servo
cold sealing servo, cutter servo

GET QUOTE

DKXL-650

Precision weighing or multi-head scales ensure consistent bag weight, with quality sensors enhancing packaging accuracy.

GET QUOTE

WP20

Automatically complete the processes of bag making, measuring, filling, sealing, bag cutting, etc., greatly improving the packaging speed.

GET QUOTE

SL400

Versatile granule packaging capability

GET QUOTE

SZ180

It is widely used in food, medicine.

GET QUOTE

Step3: Solve The Problem Of Film Walking: Alignment, Tension And Channel Cleaning

A single film jam can wipe out the output of an entire shift. Systematization of the membrane path is the fastest way to restore production.

Film Roll Alignment

Ensure that the film roll is perfectly centered on the mandrel. Misalignment is the “silent killer” that leads to deviation.

Tension Roller Calibration

If the film stretches or tears, the tension roller is usually increased. It is recommended to fine-tune the tension a little bit and test it every 1/4 turns until you find the “sweet spot” that best suits your current film thickness.

Molding Cylinder Health

Molding cylinder this place is a “dust magnet”. Static electricity will draw dust to the forming area, resulting in poor film drag. It is very important to keep the surface of the forming cylinder smooth and free of electrostatic residue.

Step4: Pneumatics And Sensing

The accuracy of packaging depends on the force and light that are invisible to the naked eye.

Uniformity Of Air Pressure PSI

Even a pressure drop of only 5 PSI can cause the actuator to slow down and cause timing errors. Check your pressure regulator and condensate filter; water in the pipeline is the number one cause of solenoid valve failure.

Sensor Calibration

The photoelectric sensor determines the length of the bag. If they are dirty or out of position, the machine will cut the wrong position. Wipe the sensor daily with a dry, lint-free cloth. If the problem still exists, check the “contrast setting” of the sensor to make sure it can clearly distinguish the color mark from the bottom film.

Establish The Habit Of Active Maintenance

Troubleshooting shouldn’t be rush of “firefighting”. By following this four-point framework—HMI monitoring, seal maintenance, membrane path optimization, and pneumatic/sensor maintenance—you can transform your team from a “repair only if it breaks” repairman to a proactive pre-judgment production engineer. Strict implementation of these procedures will be directly reflected in your OEE data, reducing waste and extending the life of those expensive packaging equipment.

Author: Marcus Chen

With over 10 years of hands-on field experience in packaging automation and maintenance, I’ve dedicated my career to cracking the code of production efficiency. I believe that troubleshooting shouldn’t be ‘firefighting’—it should be a science. My expertise lies in transforming reactive repair cultures into proactive engineering environments. By focusing on systematic diagnostics—from PLC logic and thermal sealing precision to pneumatic synchronization—I help manufacturing teams eliminate 90% of common shutdowns, extend equipment lifespans, and consistently hit their OEE targets.
